CNG Refueling Daughter Station Mobile Filling Station

FOB Reference Price:Get Latest Price
$10,000.00 - $100,000.00 / Set | 1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Sichuan, China
Brand Name:
New Tianyuan
Model Number:
Reciprocating Piston Compressor YP700/30-250
Dimension(L*W*H):
3350*2330*2700mm
Color:
Light green with stainless steel color or as per client's favourite
Weight:
7150kg
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
18 months
Configuration:
Stationary
Mute:
No
Lubrication Style:
Lubricated
Type:
Reciprocating
Voltage:
380V
Condition:
New
Certification:
SGS
Power Source:
AC POWER
Supply Ability
Supply Ability:
320 Set/Sets per Year
Packaging & Delivery
Packaging Details
Polywood box
Port
Shanghai
Lead Time :
2 months after receiving T/T or L/C
Product Description

CNG Refueling Daughter Station Mobile Filling Station

YP700/30-250 Compressor Main Parameters for Mobile CNG Refueling Station:

  1. Model: YP700/30-250;
  2. Type: P Type, horizontal, double action, reciprocating piston;
  3. Theoretical capacity: 160~1200Nm3/h (average 700 Nm3/h);
  4. Media: Desulfurized natural gas (main composition CH4);
  5. Compression stage: 2 stages;
  6. Suction status: 3.0~20.0MPa at temperature 0~35°C;
  7. Outlet discharge pressure: 25Mpa at temperature ≤45°C or less than ambient temperature 15°C(afer cooling);
  8. Oil pumpconstant power minimum adjustable pressure:  10.2MPa;
  9. Hydraulic system maximum work pressure: 16.0MPa;
  10. Total weight of skid mounted unit: 7150KG;
  11. Overall sizes of skid mounted container (LxWxH): 3350×2330×2700mm

Figure Photos







Company Information

Sichuan New Tianyuan Technologies Co., Ltd. (abbreviated as “New Tianyuan”) is commanding an international marketing and sales team composed of high-end professionals with over 20 years experience in import and export of foreign trade, joining hands in strength with several large-scale enterprises owned by Central Government and private group manufacturing companies for playing respective advantages to render customers at home and abroad with high quality and high-end technological products.

Our Services

Through untiring efforts, the sales performance and marketing share of the company is made steady progress year by year, the compressors, high pressure gas tube bundle containers, integrated equipment, vessels, transport trailor for CNG, LNG and etc.and spare parts exported have already been sold far into the five continents, spreaded all over 30 countries and regions around the world.

Packaging & Shipping

There are many modes of transportation can choose from, such as sea transportation, air trasnportation and land transportation, we will choost the most suitable transportation mode to delivery your goods. If you have any other requests, please contact us and we will get back to you in the shortest possible time, our aim is to make you satisfied.

FAQ

To have prompt and exact evaluation from factory, the following informations are essential to be provided by customer while inquiring:

1. Exact compression media: flammable, toxic, oxygen, inert gases. Preferably the gas composition can be provided;
2. Suction pressure, discharge pressure, flow capacity of compressor;
3. Control system: Requirement for manual start or full automatic control;
4. Electric parameters: Voltage, frequency, phase;
5. Any special requirement for compressed gas temperature, equipment package, configuration and etc..

We also can design piston reciprocating compressors according to clients' parameters to satisfy client's local environment and different needs. More detailed information can be provided with further communication.

If you are interested in our products,pls contact us with no hesitation.

Sichuan New Tianyuan Technologies Co., Ltd.

Tel. No.: +86 28 86799916
Fax. No.: +86 28 61668788

Website: www.chnequipment.com
WhatsApp: 008613908096496
Skype: Davidyzq
(WeChat)WeiXin: ntytech

We are sincerely waiting for your inquiry.
